1. Introdución
This manual provides essential information for the safe and effective use of your Lenovo VR180 Mirage Camera with Daydream. Please read this manual thoroughly before operating the device and retain it for future reference. The Lenovo VR180 Mirage Camera is designed to capture immersive 180-degree virtual reality photos and videos, offering a unique perspective for your content.
2. Información de seguridade
- Non expoñas a cámara a temperaturas extremas, luz solar directa nin humidade elevada.
- Evite deixar caer a cámara nin someterla a impactos fortes.
- Manteña a cámara lonxe da auga e outros líquidos.
- Non intente desmontar nin modificar a cámara. Isto anulará a garantía.
- Empregue só accesorios e adaptadores de corrente homologados.
- Clean the lenses and camera body with a soft, dry cloth. Avoid abrasive materials.
3. Contido do paquete
Verifica que todos os elementos estean presentes no paquete do teu produto:
- Lenovo VR180 Mirage Camera
- Cable USB Tipo-C
- Guía de inicio rápido
- Información de seguridade e garantía
4. Produto rematadoview
Familiarize yourself with the components and controls of your Lenovo VR180 Mirage Camera.
Figura 4.1: En ángulo view of the Lenovo VR180 Mirage Camera.
Figura 4.2: Lateral view of the camera, showing the power button, function switch, and status indicator.
Figura 4.3: Arriba view of the camera, highlighting its compact design.
Figure 4.4: Close-up of the dual fisheye lenses, each with 13 megapixels, enabling realistic 3D video recording and an enhanced immersive experience with a wide field of view. This camera is designed for a stable VR viewexperiencia ing.
Figure 4.5: Diagram illustrating the camera's controls and features. It includes a Power Button, Function Switch, Shutter Button & Status Indicator, Mode Indicator, and a Standard Tripod Mount. The camera is equipped with image stabilization, features an easy-to-use pocket size (139g), and is compatible with standard tripods.
5. Configuración
5.1. Cargando a batería
Connect the camera to a power source using the provided USB Type-C cable. The status indicator will show charging status. A full charge provides approximately 2 hours of continuous use.
5.2. Inserción dunha tarxeta microSD
Locate the microSD card slot on the side of the camera. Insert a compatible microSD card (up to 128GB) with the gold contacts facing down until it clicks into place. Ensure the card is formatted correctly for optimal performance.
5.3. Acendido inicial e emparellamento
Press and hold the Power Button to turn on the camera. Follow the on-screen instructions or refer to the quick start guide to pair the camera with your smartphone via the dedicated Daydream app. This app is essential for full functionality, including live view, settings adjustment, and content transfer.
6. Instrucións de funcionamento
6.1. Cambio de modos
Use the Function Switch to toggle between different modes, such as video recording, photo capture, and live streaming. The Mode Indicator will display the current selection.
6.2. Captura de fotos e vídeos
Press the Shutter Button to start/stop video recording or to take a photo. The status indicator will confirm recording or capture. For best results, hold the camera steady or use a tripod. The camera supports 4K/30fps video and 13-megapixel photos.
6.3. Viewe transferencia de contido
Content can be viewed directly on a compatible Daydream VR headset or transferred to your smartphone or computer via the Daydream app or by connecting the camera via USB Type-C. For optimal VR viewing, use the recommended Daydream platform.
7. Mantemento
7.1. Limpeza
Gently wipe the camera body with a soft, lint-free cloth. For lenses, use a specialized lens cleaning cloth and solution. Do not use harsh chemicals or abrasive materials.
7.2. Almacenamento
Garda a cámara nun lugar fresco e seco, lonxe da luz solar directa e de temperaturas extremas. Se a gardas durante un período prolongado, asegúrate de que a batería estea parcialmente cargada (arredor do 50 %) para prolongar a súa vida útil.
8 Solución de problemas
| Problema | Causa posible | Solución |
|---|---|---|
| Camera overheats and stops recording. | Extended recording, especially in 4K, or high ambient temperatures. | Limit continuous recording time, especially in warm environments. Allow the camera to cool down before resuming use. Consider recording in lower resolutions if prolonged recording is necessary. |
| Audio is out of sync or distorted in videos. | Software glitch or file corruption during recording/transfer. | Ensure camera firmware is up to date. Try re-recording the video. When transferring, use a stable connection and the recommended app. |
| Difficulty playing back content or slow transfer speeds. | Slow microSD card, incompatible playback device/software, or large file tamaños. | Use a high-speed microSD card (Class 10 or higher). Ensure your playback device and software are compatible with VR180 formats. Transfer files directly via USB for faster speeds. For Google Photos, be aware that it may compress images, reducing quality. |
| Significant lag between shutter press and capture. | Processing delay, especially with high-resolution settings. | Anticipate the delay when capturing critical moments. Ensure sufficient free space on the microSD card. |
| A cámara non se acende. | A batería está esgotada ou avariada. | Charge the camera fully. If the issue persists, contact support. |
| Non se pode conectar ao teléfono intelixente a través da aplicación. | Bluetooth/Wi-Fi issues, app not updated, or incorrect pairing process. | Ensure Bluetooth and Wi-Fi are enabled on your phone. Update the Daydream app to the latest version. Restart both the camera and phone, then attempt pairing again. |
9. Especificacións
| Característica | Detalle |
|---|---|
| Número de modelo | ZA3A0011JP |
| Procesador | Qualcomm APQ8053 Octa-core Processor (Max 2.2GHz) |
| Memoria principal | 2 GB |
| Memoria flash | 16 GB |
| Image Pixel Count | 13 million pixels + 13 million pixels Dual Camera |
| Calidade do vídeo | 4K/30fps, 1440p/30fps, 1080p/30fps |
| Campo de View (FOV) | Left/Right 180° x Up/Down 180° |
| Sensores | Gyro Sensor, Accelerometer Sensor |
| Conectividade sen fíos | 802.11 a/b/g/n/ac, Bluetooth 4.2 (BLE compatible) |
| Audio | Mono Speaker / Dual Microphone |
| Interface | USB Type-C port, microSD card reader (supports up to 128GB) |
| Modo de disparo | Vídeo |
| Tipo de control de exposición | Automático |
| Cor | Branco Luar |
| Tipo de medios | tarxeta microSD |
| File Formato | MP4, JPEG |
| ViewTipo de buscador | LCD |
| Light Sensitivity (ISO) | 100-3200 |
| Duración da batería (media) | 2 horas |
| Peso do produto | 139 gramos |
| Tipo de flash da cámara | Ningún |
| Función de enfoque | Enfoque automático |
| Tipo de sensor | CMOS |
10. Información da garantía
This product is covered by a limited warranty provided by Lenovo. For detailed warranty terms and conditions, please refer to the warranty card included in your product package or visit the official Lenovo support websitio. Garda o comprobante de compra para reclamacións de garantía.
11. Apoio
For technical assistance, product updates, or additional information, please visit the official Lenovo support website or contact their customer service. Support resources may include FAQs, driver downloads, and contact details for regional support centers.
Soporte oficial de Lenovo: www.lenovo.com/support
