Tefal Easy Fry Grill and Steam XXL 3-in-1 Air Fryer

1. Introdución

Welcome to the user manual for your new Tefal Easy Fry Grill and Steam XXL 3-in-1 Air Fryer. This versatile appliance combines the functions of an air fryer, grill, and steamer, offering a wide range of healthy cooking options. Please read this manual thoroughly before first use to ensure safe and optimal operation of your appliance.

Image: The Tefal Easy Fry Grill and Steam XXL 3-in-1 Air Fryer highlighting its three primary functions: Air Fry, Grill, and Steam.

2. Instrucións de seguridade importantes

Siga sempre as precaucións de seguridade básicas ao usar electrodomésticos para reducir o risco de incendio, descarga eléctrica e/ou lesións ás persoas.

• Non mergulle o aparello, o cable de alimentación nin o enchufe en auga ou outros líquidos.
• Asegurar o voltagO indicado no aparello corresponde ao seu volume de rede localtage antes de conectar.
• Manteña o aparello e o seu cable fóra do alcance dos nenos.
• Non faga funcionar ningún aparello cun cable ou enchufe danados, ou despois de que o aparello funcione mal ou teña dano dalgún xeito.
• Desconecte sempre o aparello despois de usalo e antes de limpalo. Déixeo arrefriar completamente antes de manipulalo.
• Non bloquee ningunha abertura de ventilación.
• Use só accesorios recomendados polo fabricante.
• Non coloque o aparello contra unha parede ou outros electrodomésticos. Deixe polo menos 10 cm de espazo libre na parte traseira e nos laterais e 10 cm de espazo libre enriba do aparello.
• Hot steam is released during operation, especially during steaming. Keep hands and face clear of steam.

3. Compoñentes do produto

Familiarize yourself with the parts of your Tefal Easy Fry Grill and Steam XXL.

• Unidade principal con panel de control dixital
• Cesta antiadherente extraíble
• Die-Cast Aluminum Grill Plate
• Removable Water Tank (for steaming)
• Bandexa de goteo extraíble
• Non-Stick Tray

Imaxe: Unha explosión view of the appliance, illustrating the main unit, removable non-stick basket, grill plate, water tank, and drip tray, highlighting its 6.5L capacity.

4. Configuración e primeiro uso

4.1 Desembalaxe

Carefully remove all packaging materials and promotional labels from the appliance. Keep packaging for future storage or disposal.

4.2 Limpeza antes do primeiro uso

1. Limpar a unidade principal cun anuncioamp pano.
2. Wash the removable basket, grill plate, non-stick tray, water tank, and drip tray with hot water, dish soap, and a non-abrasive sponge. These parts are also dishwasher safe.
3. Enxágüe ben e seque completamente todas as pezas.

4.3 Colocación

Place the appliance on a stable, heat-resistant, and level surface, away from walls or other appliances to allow for proper ventilation.

5. Instrucións de funcionamento

5.1 Panel de control dixital

The appliance features an intuitive digital touchscreen panel for easy operation.

Image: A close-up of the intuitive digital touchscreen panel, showing various cooking mode icons and temperature display.

• Botón de encendido: Acende/apaga o aparello.
• Control de temperatura: Axusta a temperatura de cocción.
• Control do temporizador: Sets cooking duration (up to 60 minutes).
• Selección de modo: Choose between Air Fry, Grill, Steam, or combined programs.

5.2 Air Fry Mode

Para resultados crocantes con pouco ou nada de aceite.

1. Place food in the non-stick basket.
2. Insira a cesta no aparello.
3. Select 'Air Fry' mode on the digital panel.
4. Adjust temperature and time as needed, or select a pre-set program.
5. Press start. The appliance will automatically shut off when the timer expires.

5.3 Grill Mode

Utilizes the die-cast aluminum grill plate for tender, juicy results.

1. Place the grill plate inside the non-stick basket.
2. Place food directly on the grill plate.
3. Insira a cesta no aparello.
4. Select 'Grill' mode.
5. Adjust temperature and time, then press start.

Image: A perfectly grilled piece of meat resting on the unique die-cast aluminum sizzling grill plate, designed to mimic barbecue grilling.

5.4 Steam Mode

Preserves vitamins and nutrients in your ingredients.

1. Enche o depósito de auga extraíble con auga.
2. Place the water tank into its designated slot on top of the appliance.
3. Place food in the non-stick basket.
4. Insira a cesta no aparello.
5. Select 'Steam' mode.
6. Adjust time, then press start.

Image: A hand placing the removable water tank onto the top of the appliance, indicating its use for the steaming function.

5.5 Combined Steam+Fry Function

Allows for juicy interiors and crispy exteriors.

1. Follow steps for filling the water tank (5.4).
2. Place food in the non-stick basket.
3. Insira a cesta no aparello.
4. Select a combined program (e.g., Fish, Roasted Meat) or use manual mode to combine steam and air fry.
5. Adjust settings and press start.

Image: Cooked salmon and crispy fries, demonstrating the results of the Steam+Fry function which combines steaming for moisture and air frying for crispiness.

5.6 Programas automáticos

The appliance includes 7 pre-set programs for convenience:

• Patacas fritas
• Pebidas
• Polo
• Vexetais
• Sobremesa
• Fish (combined)
• Roasted Meat (combined)

Image: A visual representation of the 7 pre-set smart programs, showing icons and examples of food items like fries, chicken, nuggets, fish, roast, vegetables, and dessert.

5.7 Manual Modes

For personalized cooking, you can use the 3 manual modes to set your own temperature and time combinations.

6. Mantemento e Limpeza

Regular cleaning ensures the longevity and optimal performance of your appliance. Always unplug the appliance and allow it to cool completely before cleaning.

6.1 Limpeza xeral

• Limpe o exterior do aparello cun anuncioamp pano. Non use produtos de limpeza abrasivos.
• Limpar o interior do aparello con anuncioamp pano e deterxente suave.

6.2 Cleaning Removable Parts

The non-stick basket, grill plate, non-stick tray, water tank, and drip tray are dishwasher safe for easy cleaning.

• Non-Stick Basket and Grill Plate: Wash with hot water, dish soap, and a non-abrasive sponge, or place in the dishwasher.
• Bandexa de goteo extraíble: This tray collects water from steaming. Empty and clean it regularly.

Image: A close-up of the removable drip tray, which collects condensation and water during steaming, indicating it should be emptied regularly.

7 Solución de problemas

Se tes problemas co teu electrodoméstico, consulta os seguintes problemas e solucións comúns:

8. Especificacións

9. Garantía e soporte

This Tefal Easy Fry Grill and Steam XXL 3-in-1 Air Fryer comes with a 1 ano de garantía desde a data de compra, cubrindo defectos de fabricación. Conserve o comprobante de compra para reclamacións de garantía.

For technical support, service, or warranty inquiries, please contact Tefal customer service through their official website or the retailer where the product was purchased. Do not attempt to repair the appliance yourself.
