ORALNER 40-Inch Electric Fireplace User Manual (Model HR-24727)

Instrucións completas para un uso seguro e eficiente.

1. Introdución

Thank you for choosing the ORALNER 40-Inch Electric Fireplace. This manual provides essential information for the safe installation, operation, and maintenance of your new electric fireplace. Please read all instructions carefully before use and retain this manual for future reference.

Información importante de seguridade

Always follow basic precautions to reduce the risk of fire, electric shock, and injury to persons.
Este aparello está quente cando está en uso. Para evitar queimaduras, non deixe que a pel espida toque superficies quentes.
Manteña os materiais combustibles, como mobles, almofadas, roupa de cama, papeis, roupa e cortinas a polo menos 3 pés (0.9 m) da parte frontal da lareira.
Non insira nin permita que entren obxectos estraños en ningunha abertura de ventilación ou escape, xa que isto pode provocar unha descarga eléctrica ou incendio, ou danar o quentador.
The fireplace features a built-in overheat protection system that automatically shuts off the heater if the temperature becomes too high.

2. Contido do paquete

Comprobe que todos os compoñentes estean presentes antes de comezar a instalación:

1 x ORALNER 40-Inch Electric Fireplace Insert
1 x mando a distancia
1 x Manual de usuario
Decorative Crystals (pre-installed or separate)

3. Especificacións do produto

Marca	ORALNER
Número de modelo	HR-24727
Dimensións do produto	40" de ancho x 21.5" de alto x 5.5" de fondo
Material	Metal, vidro temperado
Fonte de enerxía	Eléctrico con cable
Voltage	120 V, 60 Hz
Saída de calor	5,100 BTU
Wattage	750W/1500W
Temporizador	0.5 - 8 horas
Cores de chama	9 opcións
Brillo da chama	5 niveis axustables
Método de control	Touch Screen, Remote Control
Función de seguridade	Protección contra sobrecalentamiento

4. Configuración e instalación

The ORALNER electric fireplace offers flexible installation options: recessed in-wall or wall-mounted. Choose the method that best suits your space.

Directrices xerais de instalación:

Ensure the fireplace is placed on a stable, level surface or securely mounted to a wall.
Maintain a minimum of 2.5 inches (6.35 cm) of space between the top of the fireplace and any television, mantel, picture, or ceiling to allow for proper ventilation.
Non bloquee as saídas de aire.
Connect the fireplace directly to a properly grounded 120V, 60Hz outlet. Do not use extension cords.

Opcións de instalación:

This fireplace can be installed as a wall-mounted unit or recessed into a wall opening. Refer to the detailed diagrams below for specific measurements and procedures.

Diagram showing dimensions for the 40-inch electric fireplace and illustrations for wall-mounted and recessed installation types. — **Figura 4.1:** Product dimensions and visual representation of wall-mounted and recessed installation types. This image provides critical measurements for planning your installation.

Two images demonstrating the electric fireplace installed in different settings: one wall-mounted and one recessed into a brick wall. — **Figura 4.2:** Examples of the fireplace installed using both wall-mounted and recessed methods, showcasing its versatility in various room designs.

5. Instrucións de funcionamento

Your ORALNER electric fireplace can be controlled via the touch screen panel on the unit or the included remote control.

Funcións do panel de control e do mando a distancia:

Close-up image of the fireplace's touch control panel and the remote control, detailing icons for power, flame, heat, temperature, and timer settings. — **Figura 5.1:** Acabadoview of the touch control panel and remote control, highlighting the various functions for operating the fireplace.

Acendido/Apagado: Activates or deactivates the fireplace.
Cor da chama: Cycle through 9 different flame color settings.
Brillo da chama: Adjust the flame intensity with 5 adjustable brightness levels.
Quentador: Select between 750W or 1500W heat output. The fan operates to distribute heat.
Temperatura: Adjust the thermostat to your desired room temperature (62°F – 82°F).
Temporizador: Set an auto-shut off timer from 0.5 hours to 8 hours.

Efecto de chama realista:

The fireplace features realistic flame effects with decorative crystals, enhancing the ambiance of any room. You can customize the flame appearance to match your mood or decor.

A collage of nine different flame color options and a graphic illustrating five levels of flame intensity, all displayed over crystal ember beds. — **Figura 5.2:** Visual representation of the 9 flame color options and 5 adjustable brightness levels available on the ORALNER electric fireplace.

Funcionamento con baixo ruído:

Enjoy the warmth and ambiance with minimal disruption. The fireplace operates at a low noise level, typically below 35dB.

Vídeo 5.1: This video demonstrates the ORALNER electric fireplace in a living room setting, highlighting its low-noise operation and various flame effects. It shows a user operating the fireplace with the remote control.

6. Mantemento

Un mantemento regular garante a lonxevidade e o rendemento óptimo da súa lareira eléctrica.

Limpeza:

Desconecte sempre a lareira da toma de corrente antes de limpala.
Limpe as superficies exteriores cun suave, damp pano. Non use produtos de limpeza ou disolventes abrasivos.
Gently clean the tempered glass panel with a soft cloth and glass cleaner.
Ensure all vents are clear of dust and debris to maintain proper airflow.

Almacenamento:

If storing the fireplace for an extended period, unplug it and store it in a dry, dust-free location.

7 Solución de problemas

Se tes problemas coa túa lareira, consulta os seguintes problemas e solucións comúns:

Problema	Causa posible	Solución
A lareira non se acende.	No power, power switch off, or circuit breaker tripped.	Ensure the fireplace is plugged into a live outlet. Check the main power switch on the unit. Reset the circuit breaker if necessary.
Sen saída de calor.	Heater function not activated, thermostat set too low, or overheat protection engaged.	Activate the heater function. Increase the thermostat setting. If overheat protection engaged, unplug the unit, wait 10-15 minutes, and plug back in. Ensure vents are not blocked.
O efecto de chama non funciona.	Función de chama non activada.	Press the flame button on the control panel or remote to activate the flame effect.
O control remoto non funciona.	Batteries are dead or incorrect, or remote is too far from the unit.	Replace batteries (requires 2 x AAA, not included). Ensure remote is within range and pointed towards the fireplace.

Se o problema persiste despois de intentar estas solucións, póñase en contacto co servizo de atención ao cliente.

8. Información da garantía

The ORALNER 40-Inch Electric Fireplace comes with a Garantía limitada. Please refer to the warranty card included with your product for specific terms, conditions, and duration of coverage. Keep your purchase receipt as proof of purchase for any warranty claims.

9. Atención ao cliente

For any questions, assistance, or to report issues with your ORALNER electric fireplace, please contact our customer support team. Refer to the contact information provided in your product packaging or on the official ORALNER websitio.
