Introdución
Thank you for choosing the Generic Mini 4G Wireless WiFi Camera. This compact and versatile camera is designed for various surveillance needs, offering high-definition video, wide-angle viewing, and advanced features like night vision and motion detection. This manual provides detailed instructions to help you get the most out of your device.
Figura 0.1: The Mini 4G Wireless WiFi Camera can be used for various purposes, including security monitoring and observing family activities.
Produto rematadoview
Características clave
- 1080P HD Quality: Captures crystal clear video with 1080P HD resolution, ensuring vivid detail.
- 140-Degree Wide Angle Lens: Provides extensive coverage for monitoring large areas.
- 8x Zoom Capability: Allows focusing on distant objects while maintaining clarity.
- Batería de longa duración: Designed for extended operation without frequent recharging.
- Uso versátil: Suitable for home security, outdoor monitoring, and personal use.
- Visión nocturna: Experience unparalleled visibility even in complete darkness.
- Gravación de audio: Built-in pickup for clear video and surrounding sound.
- Detección de movemento: Automatically starts recording when human body sensing is triggered.
- Soporte de memoria: Supports up to 128GB memory for continuous recording.
- Deseño impermeable: Provides durability for various environmental conditions.
Vídeo de alta definición
The camera delivers true 1080P HD video, allowing you to see faces clearly up to 10 meters away. The image can be enlarged without blurring, providing superior detail compared to lower resolutions.
Figura 1.3: Visual comparison demonstrating the superior clarity and detail of 1080P HD resolution over 720P.
Contido do paquete
Verifique que todos os elementos estean presentes no seu paquete:
- Mini 4G Wireless WiFi Camera (32g variant)
- Cable de carga USB
- Manual de usuario (este documento)
Guía de configuración
1. Cargando a cámara
Before first use, fully charge the camera. Connect the provided USB charging cable to the camera's charging port and plug the other end into a standard USB power adapter (not included) or a computer USB port. The charging indicator light will show the charging status and turn off when fully charged.
2. Inserción dunha tarxeta de memoria
The camera supports up to 128GB memory cards for continuous video recording. Locate the memory card slot on the camera (refer to the diagram below) and gently insert a compatible microSD card until it clicks into place. Ensure the card is inserted in the correct orientation.
Figura 2.1: Memory card slot and approximate recording durations for different card sizes (16GB for 2 days, 32GB for 5 days, 64GB for 10 days, 128GB for 20 days).
3. Instalación da aplicación e conexión wifi
Para acceder en directo view, recordings, and settings, you need to download the dedicated mobile application. Scan the QR code provided in the camera's packaging or search for the app name (usually mentioned in a quick start guide or on the packaging) in your device's app store. Follow the in-app instructions to connect the camera to your Wi-Fi network. The camera supports both 4G and Wi-Fi connectivity.
Figura 3.1: Camera with Wi-Fi signal indicating wireless connectivity.
Instrucións de funcionamento
1. En directo View e monitorización remota
Once connected to the app, you can view the live feed from your camera remotely. This allows for real-time monitoring of your desired area. The camera's 140-degree wide-angle lens provides a broad perspective.
Figura 1.1: The Mini 4G Wireless WiFi Camera in use, demonstrating remote monitoring capabilities on a smartphone.
Figura 1.2: Examples of easy installation without punching holes, showing the camera's versatility in different indoor environments.
2. Gravación e reprodución de vídeo
The camera supports continuous video recording to the inserted memory card. You can also configure recording settings within the app, such as video recording when an alarm is triggered, all-day video recording, or regular scheduled recording. Recorded footage can be accessed and played back through the mobile application.
Figura 2.1: The camera supports both video recording and audio capture, ensuring clear sound quality without noise.
3. Visión nocturna
The camera is equipped with night vision capabilities, allowing it to capture clear images and videos even in complete darkness. This feature automatically activates in low-light conditions.
Figura 3.1: The camera provides unparalleled visibility even in complete darkness, enhancing security during nighttime.
4. Detección de movemento e alarmas
Utilize the motion detection feature to receive alerts and initiate recording when movement is detected. The camera employs human body sensing to minimize false alarms. You can customize sensitivity settings and notification preferences in the app.
Figura 4.1: Comparison of standby mode and human body sensing, where recording starts when someone passes by.
5. Funcións avanzadas
The camera offers a range of advanced functionalities accessible through the mobile application:
- Vídeo HD: High-definition recording.
- Smart Full Color: Enhanced color imaging.
- Intercomunicador de voz: Comunicación de audio bidireccional.
- Panoramic Surveillance: Gran angular view for comprehensive monitoring.
- Alarm with Voice and Light: Alerts with audible and visual indicators.
- Almacenamento na nube: Option for cloud-based video storage.
- AP Hotspot: Direct connection to the camera without a router.
- Impermeable: Provides durability for various environmental conditions.
Figura 5.1: Acabadoview of the camera's powerful functions, including HD, motion detection, voice intercom, and cloud storage.
Mantemento
1. Limpeza da cámara
To ensure optimal performance, regularly clean the camera lens and body. Use a soft, dry cloth to wipe away dust and smudges. For stubborn dirt, slightly dampen the cloth with water. Avoid using harsh chemicals or abrasive materials, as these can damage the lens or casing.
2. Coidado da batería
To prolong battery life, avoid exposing the camera to extreme temperatures. Recharge the battery when the low battery indicator appears. If storing the camera for an extended period, ensure it is partially charged (around 50%) to prevent deep discharge.
3. Actualizacións de firmware
Periodically check the mobile application for available firmware updates. Keeping your camera's firmware up-to-date ensures you have the latest features, performance improvements, and security patches. Follow the in-app instructions for any update procedures.
Resolución de problemas
| Problema | Causa posible | Solución |
|---|---|---|
| A cámara non se acende. | Batería baixa; cable/adaptador de carga defectuoso. | Charge the camera fully. Try a different USB cable and power adapter. |
| Non se pode conectar á wifi. | Incorrect Wi-Fi password; camera too far from router; router issues. | Double-check Wi-Fi password. Move camera closer to router. Restart router. Ensure camera supports your Wi-Fi band (2.4GHz usually). |
| Poca calidade de vídeo. | Dirty lens; insufficient lighting; weak Wi-Fi signal. | Clean the camera lens. Ensure adequate lighting or enable night vision. Improve Wi-Fi signal strength. |
| Recording not saving. | Memory card full or faulty; incorrect recording settings. | Check memory card capacity and format if necessary. Ensure recording settings are correctly configured in the app. Try a different memory card. |
| A aplicación falla ou conxélase. | Outdated app version; phone storage issues; software conflict. | Update the app to the latest version. Clear app cache or reinstall. Ensure your phone has sufficient storage and RAM. |
Especificacións
| Característica | Detalle |
|---|---|
| Modelo | Mini 4G Wireless WiFi Camera (32g variant) |
| Marca | Xenérico |
| Resolución de vídeo | 1080P HD |
| Ángulo da lente | Gran angular de 140 graos |
| Capacidade de zoom | Zoom óptico 8x |
| Almacenamento | Admite tarxetas MicroSD de ata 128 GB |
| Conectividade | 4G, wifi |
| Visión Nocturna | Si |
| Audio | Built-in pickup for sound recording |
| Detección de movemento | Yes (Human body sensing) |
| Fabricante | Xenérico |
Garantía e Soporte
Para obter información sobre a garantía e asistencia técnica, consulte a documentación incluída coa súa compra ou póñase en contacto directamente co vendedor. Garde o comprobante de compra para calquera reclamación de garantía.
For further assistance, please visit the product support page on the retailer's websitio ou póñase en contacto co servizo de atención ao cliente.
