Introdución
Welcome to your new CREATE WIND CLEAR EDGE Ceiling Fan with Light. This manual provides essential information for the safe installation, operation, and maintenance of your appliance. Please read it thoroughly before use and keep it for future reference.
Image: The CREATE WIND CLEAR EDGE ceiling fan with its light on and blades retracted, blending seamlessly into a modern room setting.
Instrucións de seguridade
Para garantir un funcionamento seguro e evitar danos, observe as seguintes precaucións de seguridade:
- Read all instructions carefully before installing and using the fan.
- Ensure the main power supply is disconnected at the circuit breaker before any installation, maintenance, or cleaning.
- A instalación debe ser realizada por un electricista cualificado de acordo con todos os códigos eléctricos locais.
- Mount the fan securely to a ceiling structure capable of supporting its weight (approximately 5-7 kg).
- Do not insert objects into the fan blades while the fan is in operation.
- Manteña os nenos e as mascotas lonxe do ventilador durante o funcionamento.
- Este aparello está deseñado só para uso en interiores.
- Use só o control remoto que se inclúe co ventilador.
Contido do paquete
Desembale coidadosamente todos os compoñentes e asegúrese de ter recibido os seguintes artigos:
- Ceiling Fan Unit (Motor, Integrated LED Light, Retractable Blades)
- Soporte de montaxe no teito
- Downrod
- Canopy
- Control remoto
- Ferraxes de montaxe (parafusos, ancoraxes)
- Manual de usuario
Se falta algunha peza ou está danada, póñase en contacto co servizo de atención ao cliente inmediatamente.
Configuración e instalación
AVISO: Disconnect power at the circuit breaker before beginning installation.
- Prepare o lugar de montaxe: Asegúrate de que a viga do teito ou a estrutura de soporte poidan soportar con seguridade o peso do ventilador.
- Instale o soporte de montaxe: Secure the mounting bracket to the ceiling outlet box using the provided screws. Ensure it is firmly attached and can support the fan.
- Assemble the Fan: Attach the downrod to the motor housing. Carefully feed the electrical wires through the downrod.
- Conecta o ventilador: Connect the fan's electrical wires to the household wiring according to local electrical codes. Typically, this involves connecting live, neutral, and ground wires.
- Asegurar o ventilador: Lift the fan assembly and hang it on the mounting bracket hook. Secure the canopy to cover the wiring connections.
- Instalar láminas: The WIND CLEAR EDGE features retractable blades that are typically pre-installed. Ensure they are correctly seated in their mechanism.
- Restaurar enerxía: Unha vez completada a instalación e todas as conexións estean seguras, restableza a alimentación no disxuntor.
Imaxe: Primeiro plano view of the fan's ceiling mount and downrod, showing the connection point to the ceiling. The 'CREATE' brand name is visible on the canopy.
Image: The CREATE WIND CLEAR EDGE ceiling fan with its transparent blades fully extended, viewed from below, ready for operation. The central light fixture is illuminated.
Instrucións de funcionamento
Your CREATE WIND CLEAR EDGE fan is controlled by the included remote control.
Funcións de control remoto
- Encendido/apagado: Prema o botón de acendido para acender ou apagar o ventilador e a luz.
- Velocidade do ventilador: Use the speed buttons to cycle through 6 available fan speeds.
- Control de luz:
- Prema o botón da luz para acender ou apagar a luz LED.
- Press the color temperature button to cycle through 3 LED light temperatures: warm (2700K), neutral (3300K), and cool (4000K). The light intensity is not adjustable.
- Función de temporizador: Set the fan to automatically turn off after 1 to 4 hours. (Up to 8 hours with optional Wi-Fi module and app, if purchased separately).
- Summer/Winter Function (Reverse Rotation): This function reverses the direction of the fan blades to optimize air circulation for different seasons.
- In Modo verán (counter-clockwise rotation), the fan creates a downward airflow, producing a cooling effect.
- In Modo de inverno (clockwise rotation), the fan creates an upward airflow, circulating warm air trapped near the ceiling, improving heating efficiency.
Image: A graphic illustrating key features: a timer icon with "1-4h" indicating programmable operation, a crossed-out speaker icon for silent operation, and a bar graph icon with "6" for the six-speed motor.
Image: A diagram illustrating the three available LED light color temperatures: 2700K (warm white), 3300K (neutral white), and 4000K (cool white), each represented by a lightbulb icon and corresponding Kelvin temperature.
Image: A diagram showing the fan's Summer and Winter modes. In Winter mode, arrows indicate warm air being pushed up and circulated down the walls. In Summer mode, arrows show cool air being pushed directly downwards.
Láminas retráctiles
The fan features transparent retractable blades that extend when the fan is in operation and retract when the fan is turned off, transforming the unit into an elegant light fixture.
Image: The CREATE WIND CLEAR EDGE ceiling fan installed in a room, with its transparent blades extended and the light on, actively circulating air.
Image: The CREATE WIND CLEAR EDGE ceiling fan installed in a room, with its transparent blades fully retracted, making it appear as a modern ceiling light fixture. The light is on.
Mantemento
Un mantemento regular garante un rendemento óptimo e unha maior duración do teu ventilador de teito.
- Limpeza: Desconecte a corrente antes de limpar. Use un pano suave eamp un pano para limpar a carcasa do ventilador e as aspas. Non empregue produtos de limpeza abrasivos nin disolventes.
- Inspección da lámina: Comprobe periodicamente as láminas para detectar calquera signo de danos ou desequilibrio.
- Apretar os fixadores: Over time, some fasteners may become loose. Check and tighten all screws and connections annually.
- Fonte de luz: The LED light source is integrated. Do not attempt to replace individual LEDs. If the light fails, contact customer support.
Resolución de problemas
Consulta a táboa seguinte para ver os problemas comúns e as súas solucións:
| Problema | Causa posible | Solución |
|---|---|---|
| O ventilador non comeza | Sen subministración de enerxía; Cableado solto; Pila do mando a distancia baixa. | Check circuit breaker; Verify wiring connections; Replace remote control batteries. |
| A luz non funciona | No power supply; Loose wiring; LED module failure. | Check circuit breaker; Verify wiring connections; Contact customer support for LED module replacement. |
| O ventilador tambalea | Parafusos de montaxe soltos; láminas desequilibradas. | Ensure all mounting screws are tight; Check blades for damage and ensure they are properly seated. |
| O control remoto non responde | Low battery; Obstruction between remote and receiver; Remote not paired. | Replace batteries; Remove obstructions; Refer to pairing instructions (if applicable, not provided in source). |
Especificacións
- Marca: CREAR
- Nome do modelo: WIND CLEAR EDGE M
- Número de modelo: 227415_674266
- Cor: Branco
- Deseño de ventilador eléctrico: Ventilador de teito
- Fonte de enerxía: Cable eléctrico
- Dimensións (D x W x H): 107 cm x 107 cm x 51.5 cm
- Características especiais: Remote Control, Retractable Blades, Summer/Winter Function, Integrated LED Light
- Tipo de montaxe: Montaxe no teito
- Número de velocidades: 6
- Nivel de ruído: 40 decibeis
- Potencia: 40 vatios
- Número de follas: 3
- Fluxo de aire: 172 Cubic meters per minute
- Voltage: 240 voltios
- Uso: Interior
- Material da lámina: Plástico
- Luz LED: 30W, 3 Color Temperatures (Warm 2700K, Neutral 3300K, Cool 4000K)
- Temporizador: 1-4 hours (up to 8 hours with optional Wi-Fi module)
Garantía e Soporte
For detailed warranty information or technical support, please refer to the warranty card included with your product or visit the official CREATE websitio. Conserve o recibo de compra como proba de compra para calquera reclamación de garantía.
