Introdución
This manual provides comprehensive instructions for the operation and maintenance of your Vivitar DVR880HD Digital Video Recorder. The DVR880HD is designed for capturing video in 720p resolution and still images, featuring a 2-inch LCD screen and 4x digital zoom. Please read this manual thoroughly before using your device to ensure proper function and longevity.
Figure 1: Vivitar DVR880HD Digital Video Recorder. This image shows the compact black camcorder with its 2-inch LCD screen.
Configuración
1. Cargando a batería
The Vivitar DVR880HD uses a rechargeable Lithium Ion battery. Before first use, fully charge the battery.
- Localiza o porto USB do dispositivo.
- Connect the device to a power source (e.g., computer USB port or USB wall adapter) using the provided USB cable.
- The charging indicator light will illuminate. Charging typically takes approximately 2 hours for a full charge.
- Once fully charged, the indicator light may change color or turn off. Disconnect the device from the power source.
2. Installing an SD Card
The DVR880HD requires an SD or SDXC memory card (not included) to store videos and photos as it has no internal memory.
- Locate the SD card slot on the side or bottom of the device.
- Insert the SD card into the slot with the metal contacts facing the correct direction (refer to the diagram on the device if available).
- Empurre a tarxeta suavemente ata que encaixe no seu lugar.
- Para retirala, empurre a tarxeta de novo ata que salte cara a fóra.
3. Acendido/apagado
- To power on, press and hold the Power button until the LCD screen illuminates.
- Para apagar, manteña premido o botón de acendido/apagado de novo ata que a pantalla se apague.
Instrucións de funcionamento
1. Gravación de vídeo
- Ensure the device is powered on and an SD card is inserted.
- Press the Mode button to select video recording mode (usually indicated by a camera icon with a red dot).
- Encuadra a túa foto coa pantalla LCD de 2 polgadas.
- Press the Record button (often marked with a red circle) to start recording. A red indicator light or on-screen icon will show recording is in progress.
- To stop recording, press the Record button again.
2. Facendo fotos
- Ensure the device is powered on and an SD card is inserted.
- Press the Mode button to select photo capture mode (usually indicated by a still camera icon).
- Encuadra a túa foto coa pantalla LCD de 2 polgadas.
- Press the Shutter button (often marked with a camera icon) to take a photo.
3. Uso do zoom dixital
The DVR880HD features 4x digital zoom.
- While in video or photo mode, use the zoom buttons (often marked 'W' for wide and 'T' for telephoto, or '+' and '-') to adjust the zoom level.
- Note that digital zoom may reduce image quality compared to optical zoom.
4. Conectando a un ordenador
Para transferir files, connect the DVR880HD to your computer using the supplied USB cable.
- Power on the DVR880HD.
- Conecta un extremo do cable USB ao porto USB da cámara e o outro extremo a un porto USB dispoñible no teu ordenador.
- The camera should appear as a removable disk drive on your computer.
- You can then access and transfer your video and photo files.
5. Vivitar Experience Software
The Vivitar Experience Software (if included or available for download) allows for editing and adding special effects to your captured media. Refer to the software's specific instructions for installation and usage.
Mantemento
1. Limpeza do dispositivo
- Use a soft, dry cloth to clean the exterior of the camera.
- For the LCD screen and lens, use a specialized lens cleaning cloth and solution if necessary, applying gently to avoid scratches.
- Non use produtos químicos agresivos ou materiais abrasivos.
2. Coidado da batería
- Evite descargar completamente a batería con frecuencia.
- Store the device with a partially charged battery if not used for extended periods.
- Non expoña a batería a temperaturas extremas.
3. Almacenamento
- Store the DVR880HD in a cool, dry place away from direct sunlight and excessive dust.
- Consider using a protective case to prevent physical damage.
Resolución de problemas
| Problema | Causa posible | Solución |
|---|---|---|
| O dispositivo non se acende. | A batería está descargada ou non está inserida correctamente. | Cargue a batería completamente. Asegúrese de que a batería estea inserida correctamente. |
| Cannot record videos or take photos. | Non hai ningunha tarxeta SD inserida, tarxeta SD chea ou erro na tarxeta SD. | Insira unha tarxeta SD compatible. Elimine as innecesarias files or use a new SD card. Format the SD card (refer to device settings). |
| Mala calidade de imaxe/vídeo. | Insufficient lighting, dirty lens, or digital zoom used excessively. | Ensure adequate lighting. Clean the lens. Avoid using maximum digital zoom in low light. |
| O ordenador non recoñece o dispositivo. | Faulty USB cable, incorrect connection, or driver issue. | Try a different USB port or cable. Ensure the camera is powered on when connected. Restart your computer. |
| A batería esgotarase rapidamente. | Frequent use of LCD, recording, or battery aging. | Reduce LCD brightness. Limit continuous recording. Consider replacing the battery if it's old. |
Especificacións
| Característica | Detalle |
|---|---|
| Número de modelo | DVR880HD |
| Pantalla de visualización | LCD de 2 polgadas |
| Resolución de vídeo | 720p HD |
| Zoom dixital | 4x |
| Tecnoloxía do sensor fotográfico | CMOS |
| Tipo de memoria flash | SDXC (SD Card Supported) |
| Conectividade | USB |
| Tipo de batería | Ion de litio (incluído) |
| Dimensións (L x W x H) | 7.5 x 2.5 x 9 polgadas |
| Peso do elemento | 4.8 onzas |
| Formato de audio compatible | AAC, AC-3 |
Garantía e Soporte
For warranty information and technical support, please refer to the documentation provided with your purchase or visit the official Vivitar websitio.
