Introdución
This manual provides comprehensive instructions for the installation, operation, and maintenance of your One For All Signal Amplifier SV 9620. Please read this manual thoroughly before using the device to ensure proper functionality and safety. The SV 9620 is designed to amplify TV signals, improving reception quality for multiple televisions in your home.
Información de seguridade
- Asegurar o amplifier is connected to a 220 Volt power supply as specified. Connecting to an incorrect voltage may damage the device and pose a safety risk.
- Non expoñas o dispositivo á choiva, á humidade nin a temperaturas extremas.
- Non abras a c.asing do amplifier. There are no user-serviceable parts inside. Refer all servicing to qualified personnel.
- Manteña o dispositivo lonxe de fontes de calor e da luz solar directa.
- Garantir unha ventilación adecuada ao redor amplifier para evitar o sobrequecemento.
- Disconnect the power plug from the wall outlet during lightning storms or when unused for long periods.
Contido do paquete
Marque a caixa para os seguintes elementos:
- One For All Signal Amplifier SV 9620 Unit
- Integrated Power Plug
- Manual de usuario (este documento)
Figure 1: The retail packaging of the One For All Signal Amplifier SV 9620, showing the product name and key features.
Configuración
Follow these steps to set up your signal ampmáis vivo:
- Identify the Signal Source: Locate the main antenna or cable TV input point in your home. This is typically where the signal enters your house.
- Connect Input: Connect the coaxial cable from your antenna or cable TV wall outlet to the "IN" port on the One For All Signal Amplifier SV 9620.
- Connect Outputs: Connect coaxial cables from the "OUT" ports of the amplifier to the antenna/cable input of your televisions. The SV 9620 is a 2-fold amplifier, meaning it has two output ports for connecting up to two televisions.
- Encendido: Plug the integrated power plug of the amplifier into a standard 220 Volt wall outlet. An indicator light on the amplifier should illuminate, confirming it is receiving power.
- Busca canles: On each connected television, perform a channel scan or auto-tune function to detect available channels with the amplified signal. Refer to your television's user manual for specific instructions on channel scanning.
Figure 2: An illustrative diagram demonstrating how the signal amplifier connects to the main signal source and distributes the amplified signal to two televisions within a household.
Figura 3: Detalle view of the One For All Signal Amplifier SV 9620, highlighting its compact design and the input/output ports for coaxial cable connections.
En funcionamento
Once properly installed, the One For All Signal Amplifier SV 9620 operates continuously to boost your television signal. There are no user controls or adjustments required during normal operation. The amplifier is designed for "Plug & Play" functionality.
- O amplifier provides a 20dB gain, which helps overcome signal loss due to long cable runs or splitting the signal to multiple TVs.
- It includes an interference-free 4G/LTE filter to minimize disruptions from mobile phone signals, ensuring crystal clear reception.
Mantemento
The One For All Signal Amplifier SV 9620 requires minimal maintenance.
- Limpeza: Desconecta o amplifier from the power outlet before cleaning. Use a soft, dry cloth to wipe the exterior of the unit. Do not use liquid cleaners or abrasive chemicals.
- Almacenamento: Se almacena o amplifier for an extended period, disconnect it from power and signal cables. Store it in a cool, dry place, away from direct sunlight and extreme temperatures.
Resolución de problemas
If you experience issues with your signal amplifier, consulte os seguintes problemas e solucións comúns:
| Problema | Causa posible | Solución |
|---|---|---|
| No signal or poor picture quality after installation. |
|
|
| Picture is worse than before ampmáis vivo. |
|
|
| Only one TV receives a good signal. |
|
|
Especificacións
| Característica | Detalle |
|---|---|
| Número de modelo | SV 9620 |
| Marca | Un Para Todos |
| Ganancia | 20dB (2-fold) |
| Voltage | 220 voltios |
| Tipo de montaxe | Montaxe en superficie |
| Dimensións do produto (L x W x H) | 3.94 x 3.94 x 3.94 polgadas |
| Peso do elemento | 6.7 onzas |
| Fabricante | Un Para Todos |
Garantía e Soporte
One For All products are manufactured to high quality standards. For information regarding warranty terms and conditions, please refer to the warranty card included with your product or visit the official One For All website. For technical support or further assistance, please contact One For All customer service through their official channels.
Podes atopar máis información e recursos de apoio en One For All Store on Amazon.
