1. Introdución
The Flashpoint Zoom Li-Ion Mini R2 TTL Flash is a compact and powerful flash unit designed for use with select Sony mirrorless cameras, including models such as A7RIII, a7rII, a7R, a58, a99, ILCE6000L, a77II, RX10, and the a9. This flash features an integrated R2 radio transceiver, enabling wireless triggering and control. It can function as a master unit to command other Flashpoint and Godox R2-compatible slave units, offering versatile lighting solutions for various photographic scenarios.
2. Precaucións de seguridade
- Non desmontes nin modifiques a unidade de flash. As reparacións só deben ser realizadas por persoal de servizo autorizado.
- Manteña o flash seco. Non o expoña á choiva, á humidade ou a unha humidade elevada.
- Do not touch the flash tube after firing, as it can be hot.
- Manter fóra do alcance dos nenos.
- Use only the specified battery and charger. Improper use can lead to fire, explosion, or electric shock.
- Evita a exposición directa dos ollos ao flash, especialmente a curta distancia, xa que pode prexudicar a visión.
3. Produto rematadoview
3.1 Contido do paquete
- Flashpoint Zoom Li-Ion Mini Flash Unit
- Mini soporte
- Caso de protección
- Diffuser (assumed from 'Dif' in product data)
3.2 Flash Components
Familiarize yourself with the main components of your Flashpoint Zoom Li-Ion Mini R2 TTL Flash.
Figura 3.2.1: Fronte view of the Flashpoint Zoom Li-Ion Mini R2 TTL Flash, showing the flash head and main body.
Figura 3.2.2: Traseira view of the flash, highlighting the LCD display and control buttons for mode, zoom, sync, and power.
Figura 3.2.3: The flash unit with its built-in wide-angle diffuser panel extended from the flash head.
4. Configuración
4.1 Instalación da batería
- Localice o compartimento da batería no lateral da unidade de flash.
- Slide the battery cover release latch and open the compartment.
- Insert the Li-Ion battery, ensuring correct polarity as indicated inside the compartment.
- Peche a tapa do compartimento da batería ata que encaixe firmemente no seu lugar.
Figura 4.1.1: Lado view of the flash unit, indicating the battery compartment with a 'BATT.PUSH' label.
4.2 Montaxe na cámara
- Asegúrese de que a unidade de flash estea apagada.
- Slide the flash's hot shoe foot into your Sony camera's hot shoe mount.
- Tighten the locking ring on the flash foot to secure it to the camera. Do not overtighten.
4.3 Acendido/Apagado
Press and hold the power button (usually marked with a ⚡ or power symbol) on the rear control panel to turn the flash on or off.
5. Instrucións de funcionamento
5.1 Modos de funcionamento básicos
The Flashpoint Zoom Li-Ion Mini R2 TTL Flash supports various operating modes:
- Modo de flash automático TTL: Automatically sets the flash output for correct exposure.
- Modo manual (M): Permite o axuste manual da potencia de saída do flash.
- Modo múltiple (estroboscópico): Dispara unha serie de flashes rápidos durante unha única exposición.
- Modos escravos ópticos S1/S2: Triggers the flash optically when another flash fires.
Usa o MODO button on the control panel to cycle through these modes.
Figura 5.1.1: Detallado view of the flash control panel, showing buttons for MODE, ZOOM, SYNC, SLAVE, GR/CH, and the SET dial.
5.2 R2 Wireless System
The integrated R2 radio transceiver provides wireless control. Set the flash to Master or Slave mode and configure the group (GR) and channel (CH) settings to match your R2-compatible transmitter or other R2 flashes. Refer to your R2 transmitter's manual for detailed wireless setup.
5.3 Axuste da cabeza do flash
The flash head can be rotated and tilted to bounce light off ceilings or walls for softer illumination.
- Rotación horizontal: 0 a 270 graos.
- Inclinación vertical: -7 a 90 graos.
Figura 5.3.1: Illustration demonstrating the flexible rotation and tilt capabilities of the flash head.
5.4 Función de zoom
The flash features an automatically zooming flashhead from 24-105mm. This adjusts the flash coverage to match the focal length of your lens. In manual mode, you can also adjust the zoom manually using the ZOOM botón.
6. Mantemento
- Limpeza: Use un pano suave e seco para limpar a unidade de flash. Para a sucidade persistente, use un pano lixeiramente seco.amp cloth with mild detergent, then wipe dry. Do not use organic solvents like thinner or benzene.
- Almacenamento: When not in use for extended periods, remove the battery and store the flash in a cool, dry place, preferably in its protective case.
- Coidado da batería: Recharge the Li-Ion battery regularly, even if not in use, to maintain its lifespan. Avoid fully discharging the battery.
7 Solución de problemas
If you encounter issues with your Flashpoint Zoom Li-Ion Mini R2 TTL Flash, refer to the following common problems and solutions:
| Problema | Posible causa/solución |
|---|---|
| O flash non se dispara. | Check if the flash is powered on. Ensure the battery is charged and correctly installed. Verify the flash is securely mounted on the camera hot shoe. Check camera flash settings. |
| Flash output is inconsistent or incorrect. | Ensure TTL mode is selected for automatic exposure, or adjust manual power settings. Check for obstructions between the flash and subject. Verify flash head zoom matches lens focal length. |
| Falla a activación sen fíos. | Confirm that the flash and transmitter are set to the same R2 group and channel. Ensure both units are within range and have fresh batteries. Check for radio interference. |
| Difficulty mounting flash on camera hot shoe. | Ensure the locking ring is fully loosened. Some camera hot shoes may have tighter tolerances; apply firm, even pressure. If persistent, verify compatibility with your specific camera model. |
| Unable to update firmware via micro-USB port. | The micro-USB port may be recessed. Try using a micro-USB cable with a very slim connector housing. If issues persist, contact Flashpoint customer support for guidance on compatible cables or alternative update methods. |
8. Especificacións
| Característica | Especificación |
|---|---|
| Número de guía | 82ft / 25m (at ISO 100) |
| Tempo de reciclaxe | 0.1 a 1.7 segundos |
| Alcance do zoom | 24-105 mm (Automático/Manual) |
| Bounce Head Rotation | Horizontal: 0 to 270 degrees |
| Bounce Head Tilt | Vertical: -7 to 90 degrees |
| Dimensións (L x W x H) | 8.4 x 7.2 x 2.8 polgadas |
| Peso do elemento | 1.87 libras |
| Montaxes compatibles | Sony Alpha |
| Número de modelo | Zoom-Lion Mini |
| ASIN | B07CV42KFV |
9. Garantía e soporte
9.1 Información da garantía
Flashpoint products typically come with a limited manufacturer's warranty. For specific details regarding the warranty period and terms for your Zoom Li-Ion Mini R2 TTL Flash, please refer to the warranty card included with your product or visit the official Flashpoint websitio.
9.2 Atención ao cliente
For technical assistance, troubleshooting beyond this manual, or service inquiries, please contact Flashpoint customer support. Contact information can usually be found on the Flashpoint websitio web ou na documentación do produto.
