GMKtec Mini PC 12th Intel N95 User Manual

1. Introdución

This manual provides detailed instructions for setting up, operating, and maintaining your GMKtec Mini PC. Designed for efficiency and performance, this compact desktop computer is equipped with the Intel 12th Gen N95 processor, offering robust capabilities for home and office use. Please read this manual thoroughly to ensure proper usage and to maximize the lifespan of your device.

2. Contido do paquete

Upon opening your GMKtec Mini PC package, please verify that all the following items are included:

• Host (GMKtec Mini PC) x 1
• Adaptador de alimentación x 1
• AC line x 1
• Accessory screw bag x 1
• Manual x 1
• Tarxeta de garantía x 1

Image: All items included in the GMKtec Mini PC package.

3. Produto rematadoview

The GMKtec Mini PC is designed for compact efficiency, measuring approximately 2.83 x 2.83 x 0.72 inches and weighing about 0.79 pounds. Its small footprint makes it ideal for space-saving setups.

Imaxe: Fronte e parte traseira views of the GMKtec Mini PC, highlighting its compact design.

3.1. Portos e conectores

Familiarize yourself with the available ports for connecting peripherals and displays:

• Panel frontal:
• USB-A 3.2 Gen2 Ports (x2): For high-speed data transfer (10 Gbps) and connecting USB devices.
• Power Button: To turn the device on/off.
• Panel traseiro:
• DC Port (20V 5A): For power input.
• HDMI Ports (x2): Supports dual 4K@60Hz display output.
• RJ45 (2.5G) Gigabit Ethernet Port: For high-speed wired network connection.
• USB-A 3.2 Gen2 Ports (x2): Additional high-speed USB ports.
• Audio (3.5mm CTIA): For headphones or speakers.

Imaxe: Detallada view of the front and rear ports and their functions.

3.2. Características clave

• Powerful Intel 12th Gen N95 Processor: Features a 10nm 4-core, 4-thread CPU with Turbo up to 3.4GHz, 6MB L3 Smart Cache, and 15W TDP, offering enhanced performance over previous generations.
• High-Speed Storage and Expandability: Comes with 8GB DDR4 RAM and a 512GB M.2 2280 NVMe (PCIe3.0) SSD. Supports expansion up to 2TB for NVMe and an additional M.2 2242 SATA slot for up to 1TB.
• Conectividade avanzada: Equipped with Dual-band Wi-Fi 6 (2.4G+5G) and Bluetooth 5.2 for faster and more stable wireless connections. Includes a 2.5G Gigabit Ethernet port for high-speed wired networking.
• Dual 4K Display Support: Features two HDMI 2.0 ports supporting simultaneous 4K@60Hz display output for a clear and smooth visual experience.
• Refrixeración eficiente: Utilizes a superconducting copper twin turbo cooling design with two-way convection air inlet for quiet and effective heat dissipation.
• Compacto e portátil: Its small size and light weight make it easy to transport and save desk space.

Image: Illustration of the efficient cooling system within the Mini PC.

Image: Comparison of Wi-Fi 5 vs. Wi-Fi 6 speeds and Bluetooth 5.2 capabilities.

Image: Illustration of 2.5G Gigabit LAN speed and connection.

4. Configuración

Follow these steps to set up your GMKtec Mini PC:

1. Conectar á enerxía: Plug the AC line into the power adapter, then connect the power adapter to the DC port on the rear of the Mini PC. Plug the AC line into a wall outlet.
2. Conectar á pantalla: Use an HDMI cable to connect your monitor(s) to the HDMI port(s) on the rear of the Mini PC. For dual display, connect both HDMI ports to separate monitors.
3. Conectar periféricos: Connect your keyboard, mouse, and any other USB devices to the available USB 3.2 ports on the front or rear of the Mini PC.
4. Conexión de rede: For a wired connection, connect an Ethernet cable from your router or modem to the RJ45 port on the rear. For wireless, ensure your Wi-Fi network is available and you have the password ready for setup within Windows.
5. Encendido: Press the power button on the front of the Mini PC. The system will boot up, and you can proceed with the Windows 11 Pro initial setup.

4.1. Montaxe VESA

The GMKtec Mini PC supports VESA installation, allowing you to mount it behind a compatible monitor to save desk space.

Image: Desktop placement and VESA installation options for the Mini PC.

5. Instrucións de funcionamento

Once your Mini PC is set up, you can begin using it for various tasks:

• Configuración inicial de Windows: Follow the on-screen prompts to complete the Windows 11 Pro setup, including region, keyboard layout, network connection, and user account creation.
• Conectando a wifi: If not using a wired connection, navigate to Windows Settings > Network & Internet > Wi-Fi, select your network, and enter the password.
• Configuración de pantalla dual: After connecting two monitors via HDMI, Windows should automatically detect them. If not, right-click on the desktop, select 'Display settings', and configure the display mode (e.g., Extend, Duplicate).
• Saída de audio: Connect speakers or headphones to the 3.5mm audio jack or use HDMI audio if your monitor supports it. Adjust audio settings in Windows Sound settings.
• Shut Down/Restart: Use the standard Windows Start menu options to shut down, restart, or put the computer to sleep.

Image: The Mini PC supporting dual 4K displays for enhanced productivity or entertainment.

6. Mantemento

Un mantemento regular axuda a garantir a lonxevidade e o rendemento óptimo do seu mini PC:

• Limpeza: Regularly clean the exterior with a soft, dry cloth. Use compressed air to gently clear dust from the ventilation grilles to prevent overheating. Do not use liquid cleaners directly on the device.
• Actualizacións de software: Manteña o sistema operativo e os controladores de Windows actualizados para garantir a seguridade e o rendemento.
• Xestión de almacenamento: Periodically check your storage usage and delete unnecessary files para liberar espazo.
• Condicións ambientais: Operate the Mini PC in a well-ventilated area, away from direct sunlight, excessive heat, humidity, or dust.

6.1. Storage and RAM Expansion

The GMKtec Mini PC allows for easy expansion of RAM and storage:

• RAM: Supports DDR4 SO-DIMM, max 32GB.
• SSD: Pre-installed with M.2 2280 NVMe (PCIe3.0) SSD, expandable up to 2TB. An additional M.2 2242 SATA slot is available for expansion up to 1TB.

For expansion, gently remove the bottom cover. Refer to the internal layout for component placement. Ensure the device is powered off and unplugged before performing any internal modifications.

Imaxe: Interna view of the Mini PC, illustrating RAM and SSD expansion options and installation steps.

7 Solución de problemas

If you encounter issues with your GMKtec Mini PC, refer to the following common problems and solutions:

If the problem persists after trying these solutions, please contact GMKtec customer support.

8. Especificacións

Detailed technical specifications for your GMKtec Mini PC:

Image: Key specifications and features of the GMKtec Mini PC.

Image: Performance comparison of the Intel N95 processor against other Celeron models.

9. Garantía e soporte

GMKtec is committed to providing reliable, high-quality products and professional after-sales service. Your GMKtec Mini PC comes with a warranty and dedicated support.

• Garantía: The product includes a warranty, typically 12 months of satisfying service. Please refer to your warranty card for specific terms and conditions.
• Soporte técnico: GMKtec offers lifetime technical support for its products.
• Contacto con Soporte:
• For product questions, you can log into your Amazon account, go to 'Your Orders', and select 'Ask Product Question'.
• Alternatively, you can reach out via email: support@gmktec.com
