HOMCOM LED Bathroom Mirror Instruction Manual

1. Información de seguridade

Always unplug the mirror when not in use. Be cautious when handling the mirror to avoid breakage. Ensure the mirror is securely mounted to the wall using the provided hardware. If hardwired, consult a professional. Keep the mirror away from direct contact with water.

2. Produto rematadoview

The HOMCOM LED Bathroom Mirror (Model 834-700V81CR) is designed to provide enhanced illumination and functionality for your bathroom. It features dual lighting sources, adjustable settings, and an anti-fog function for convenience.

Características principais:

• Backlit & Front-Lit: Dual lighting sources provide ample brillo para varias tarefas.
• Adjustable Brightness & Color Temperature: Customize lighting from 6500K to 3000K, with a near-infinite adjustment range.
• Función anti-néboa: Integrated defogger ensures a clear mirror surface, automatically turning off after 1 hour.
• Función de memoria: Retains your last brightness and color temperature settings.
• Construción de alta calidade: CRI90+ rating, 5mm copper-free HQ silver-coated glass, explosion-proof film, and IP44 waterproof rating.
• Instalación versátil: Can be mounted vertically or horizontally, with options for plug-in or hardwired connection.

Image: The HOMCOM LED Bathroom Mirror illuminated, showcasinpolo seu deseño elegante e a iluminación integrada.

Image: An infographic highlighting the mirror's features: Dimmable, Front-Lit/Backlit, Horizontal/Vertical mounting, Anti-Fog, Memory Function, Waterproof, and Plug-in/Hardwired options.

3. Configuración e instalación

The mirror is designed for easy installation and can be mounted either vertically or horizontally. All necessary mounting hardware is included.

Pasos de instalación:

1. Desempaquetar: Carefully remove the mirror and all components from the packaging. Inspect for any damage.
2. Escolla localización: Select a suitable wall location in your bathroom, ensuring it is free from obstructions and has access to a power source.
3. Marcar puntos de montaxe: Use the provided wall brackets and a level to mark the drilling points on the wall for either vertical or horizontal orientation.
4. Perforación: Drill holes at the marked points and insert appropriate wall anchors (if necessary for your wall type).
5. Soportes seguros: Attach the wall brackets securely to the wall using screws.
6. Conexión de alimentación:
   • Enchufe: If using the plug-in option, ensure the power cord can reach a suitable outlet.
   • Cableado: If opting for a hardwired connection, it is strongly recommended to consult a qualified electrician to handle the wiring. Ensure power is turned off at the circuit breaker before beginning any hardwiring.
7. Espello de montaxe: Carefully lift the mirror and align the mounting points on the back of the mirror with the wall brackets. Secure the mirror in place.
8. Funcionalidade de proba: Once mounted and connected to power, test all functions (lights, anti-fog, brightness, color temperature).

Image: Illustration demonstrating the two power connection methods: direct plug-in to an outlet or hardwired installation, which may require professional assistance.

Image: A diagram showing the mirror's dimensions: 35.4 inches in length and 27.6 inches in width.

4. Instrucións de funcionamento

The HOMCOM LED Bathroom Mirror features intuitive touch controls for its various functions.

Controis:

• Encendido/apagado: Tap the power button icon to turn the lights on or off.
• Axustar o brillo: When the lights are on, long-press the power button icon to adjust the brightness level. The mirror will cycle through brightness levels; release when desired brightness is reached.
• Cambiar a temperatura da cor: Short-press the color temperature icon to cycle through three preset color temperatures: 6500K (Cool White), 3000K (Warm White), and 4500K (Neutral White).
• Infinite Color Temperature Adjustment: Long-press the color temperature icon for a wider range of color temperature customization between 6500K and 3000K.
• Función anti-néboa: Tap the anti-fog icon to activate the defogger. The defogger will automatically turn off after 1 hour.
• Función de memoria: The mirror will remember your last brightness and color temperature settings when powered off and on again.

Image: An illustration detailing how to adjust brightness by holding the ON/OFF button and the memory function that retains settings.

Image: An illustration explaining how to short-press for three color temperatures (3000K, 4500K, 6500K) and long-press for infinite color temperature customization.

Image: A visual representation of the anti-fog function in action, showing a clear mirror surface in a steamy bathroom environment.

5. Mantemento

Proper maintenance will ensure the longevity and optimal performance of your HOMCOM LED Bathroom Mirror.

• Limpeza da superficie do espello: Usa un pano suave e sen pelusa e un limpacristais non abrasivo. Pulveriza o limpador sobre o pano, non directamente sobre o espello, para evitar que o líquido se filtre nos compoñentes eléctricos.
• Limpeza do cadro: Limpe a estrutura de aluminio cun pano suave eamp pano. Evite produtos químicos agresivos ou produtos de limpeza abrasivos.
• Compoñentes eléctricos: Ensure the mirror is unplugged or the power is turned off at the circuit breaker before cleaning any part of the mirror, especially near electrical connections.
• Evitar a humidade excesiva: While the mirror has an IP44 waterproof rating, avoid directly spraying water onto the mirror's edges or electrical components.

6 Solución de problemas

If you encounter any issues with your mirror, please refer to the following troubleshooting guide before contacting customer support.

7. Especificacións

8. Garantía e soporte

For warranty information or technical support, please contact HOMCOM customer service directly. Keep your purchase receipt and model number (834-700V81CR) handy for faster service.

You can find contact information on the official HOMCOM websitio web ou a través do seu vendedor.
